Race Spec® Exclusive Rennsteig Molex CMC Die Set
Suitable for .635mm and 1.5mm Molex CMC contacts
0.635mm contact wire gauge 20-22AWG
22AWG with contact 64322-1019
20AWG with contact 64322-1039
1.5mm contact Wire gauge 18-20AWG
20AWG with contact 64323-1029
18AWG with contact 64323-1039
Only the contacts listed above can be used. The use of other contact part numbers or wire cross-sections is not recommended.
As an authorised Rennsteig distributor with a direct link to the head office in Germany, Race Spec has collaborated to launch a new die set specifically designed for M22759/32 cables. The die set is compatible with various Molex CMC series contacts and has a nest for 18AWG, 20AWG and 22AWG.
A Rennsteig PEW12 crimping tool is also required.
